1G SFP Module Hot Swappable for Network Switch
1G SFP Module Hot Swappable for Network Switch
• High-Speed Data Transmission: supports 1Gbps Ethernet transmission rate for enterprise and telecommunications applications.
• Dual-Fiber Transmission: uses a dual-fiber LC interface with two optical fibers for stable, reliable data transmission.
• Single-Mode Fiber: suitable for long-distance transmission from several kilometers to tens of kilometers.
• Digital Diagnostic Function (DDM/DOM): monitors optical power, temperature, and voltage in real time.
• Dual-Fiber Transmission: uses a dual-fiber LC interface with two optical fibers for stable, reliable data transmission.
• Single-Mode Fiber: suitable for long-distance transmission from several kilometers to tens of kilometers.
• Digital Diagnostic Function (DDM/DOM): monitors optical power, temperature, and voltage in real time.
Product Introduction
This series of EW-F6081P optical transceiver modules is compatible with Cisco, Juniper, Huawei, ZTE, H3C, Mellanox, DELL, Intel, Ubiquiti, FiberHome, Ruijie, D-LINK, Netgear, Ciena, Arista, Brocade, Extreme, Avago, Avaya, Nortel, Alcatel-Lucent, Dahua, and Hikvision equipment, suitable for data centers and telecommunications networks. The SFP transceivers are high performance, cost effective modules supporting a data-rate of 1.25Gbps and 20km transmission distance on 9/125μm SMF.Key Advantages
- SFP Dual Fiber Single Mode: received and sent data are transmitted on two optical fibers, one for sending (Tx) and one for receiving (Rx), suitable for scenarios with high requirements for signal transmission quality and stability
- Widely Compatible: adapts to major brand models, suitable for switches, routers, network cards, transceivers and other SFP-equipped devices
- DDM Detection: real-time monitoring of module working status helps predict and locate faults
- Imported Chips, Stable Transmission: high-quality main control chip and thickened gold-plated finger technology with real-time automatic calibration
Product Features
- Uncooled Laser Diode with MQW Structure
- InGaAs PIN-TIA Photodiode Receiver
- Reach 20 km Transmission Distance on 9/125μm SMF
- BIDI Single Mode Transceiver SFP Footprint
- LC or SC Optical Interface Are Optional
- Compliant With SFP MSA and SFF-8472
- Digital Diagnostic Monitoring Interface
- Single +3.3V Power Supply
- LVPECL Differential Inputs and Outputs
- LVTTL Signal Detection Output
- Compliant With ITU-T G.957
- Compliant With RoHS and Lead Free
- Metal Enclosure for Lower EMI
Product Applications
- Gigabit Ethernet
- Fiber Channel
- ATM/SONET/SDH/Switch/Router
- Other Optical Transmission Systems
