25G SFP Module on Switch Compatible with Juniper
25G SFP Module on Switch Compatible with Juniper
Cost-Effectiveness: a more cost-effective upgrade path, especially leveraging existing cabling infrastructure.
Backward Compatibility: many SFP28 modules support dual-rate, compatible with both 10GbE and 25GbE.
Easy Deployment and Maintenance: hot-swappable module, very easy to install, replace and maintain.
Digital Diagnostic Function: monitor optical power, temperature, voltage, etc. in real time.
Compatible Brands: Cisco, Juniper, Huawei, ZTE, H3C, Mellanox, DELL, Intel, Ubiquiti, FiberHome, Ruijie, D-LINK, Netgear, Ciena, Arista, Brocade, Extreme, Avago, Avaya, Nortel, Alcatel-lucent, Dahua, Hikvision, Ericsson, MikroTik, Fortinet, Nokia, Nvidia, etc.
Product Overview
EW-F6071P Single-Fiber Single-Mode is a high-performance 25G BIDI optical module that supports long-reach transmission up to 10 kilometers. Utilizing advanced DFB lasers, it provides data transmission rates of up to 25.78Gbps. This module complies with the IEEE 802.3cc standard and supports digital diagnostic functions, making it suitable for data centers, 5G networks, and enterprise networks. HSGQ-SFP28-25G-10LR-33B/HSGQ-SFP28-25G-10LR-27A is a high-performance, cost-effective module with transmission distance up to 10km, consisting of a transmitter section (1270nm DFB for 27A, 1330nm DFB for 33B) and a PIN photodiode receiver with integrated transimpedance preamplifier (TIA).
Key Advantages
- High-Speed Transmission, Low Latency: up to 25.78Gbps for data centers, 5G networks, and enterprise networks
- Intelligent Diagnostics, Real-Time Monitoring: digital diagnostic monitoring (DDM) via 2-wire serial interface per SFF-8472
- Low-Power Design: maximum power consumption of only 1W
- Diverse Network Needs: compliant with SFF-8431, SFF-8472, and SFP28 MSA specification
Technical Parameter
| Item | SFP28-25G-10LR-27A/33B |
|---|---|
| Data Rate | Up to 25.78Gb/s bi-directional data links |
| Wavelength | Uncooled 1270nm DFB Laser (27A); Uncooled 1330nm DFB Laser (33B) |
| Transmission Distance | Up to 10km on 9/125um SMF |
| Connector | Simplex LC connector compliant |
| Power Supply | Single +3.3V DC power supply |
| Operating Temperature | Commercial: 0 to 70°C; Industrial: -40 to 85°C |
| Compatible Brands | Cisco, Juniper, Huawei, ZTE, H3C, Mellanox, DELL, Intel, Ubiquiti, FiberHome, Ruijie, D-LINK, Netgear, Ciena, Arista, Brocade, Extreme, Avago, Avaya, Nortel, Alcatel-lucent, Dahua, Hikvision, Ericsson, MikroTik, Fortinet, Nokia, Nvidia, etc. |
Product Features
- Compliant with SFF-8431 and SFF-8472; Compliant with SFP28 MSA Specification
- Digital Diagnostic Monitoring available via 2-wire serial interface
- Up to 25.78Gb/s bi-directional data links, up to 10km on 9/125um SMF
- Hot-pluggable SFP footprint, Class 1 laser safety certified
- Low power dissipation, RoHS compliance
| Data Rate | Up to 25.78Gb/s bi-directional |
| Wavelength | 1270nm DFB (27A) / 1330nm DFB (33B) |
| Transmission Distance | Up to 10km on 9/125um SMF |
| Connector | Simplex LC connector |
| Power Supply | Single +3.3V DC |
- Compliant with SFF-8431, SFF-8472, and SFP28 MSA Specification
- Digital Diagnostic Monitoring available
- Up to 25.78Gb/s bi-directional data links, up to 10km on SMF
- Hot-pluggable SFP footprint, Class 1 laser safety certified
Product Overview
EW-F6071P Single-Fiber Single-Mode is a high-performance 25G BIDI optical module that supports long-reach transmission up to 10 kilometers. Utilizing advanced DFB lasers, it provides data transmission rates of up to 25.78Gbps. This module complies with the IEEE 802.3cc standard and supports digital diagnostic functions, making it suitable for data centers, 5G networks, and enterprise networks. HSGQ-SFP28-25G-10LR-33B/HSGQ-SFP28-25G-10LR-27A is a high-performance, cost-effective module with transmission distance up to 10km, consisting of a transmitter section (1270nm DFB for 27A, 1330nm DFB for 33B) and a PIN photodiode receiver with integrated transimpedance preamplifier (TIA).Key Advantages
- High-Speed Transmission, Low Latency: up to 25.78Gbps for data centers, 5G networks, and enterprise networks
- Intelligent Diagnostics, Real-Time Monitoring: digital diagnostic monitoring (DDM) via 2-wire serial interface per SFF-8472
- Low-Power Design: maximum power consumption of only 1W
- Diverse Network Needs: compliant with SFF-8431, SFF-8472, and SFP28 MSA specification
Technical Parameter
| Item | EW-F6071P |
|---|---|
| Data Rate | Up to 25.78Gb/s bi-directional data links |
| Wavelength | Uncooled 1270nm DFB Laser (27A); Uncooled 1330nm DFB Laser (33B) |
| Transmission Distance | Up to 10km on 9/125um SMF |
| Connector | Simplex LC connector compliant |
| Power Supply | Single +3.3V DC power supply |
| Operating Temperature | Commercial: 0 to 70°C; Industrial: -40 to 85°C |
| Compatible Brands | Cisco, Juniper, Huawei, ZTE, H3C, Mellanox, DELL, Intel, Ubiquiti, FiberHome, Ruijie, D-LINK, Netgear, Ciena, Arista, Brocade, Extreme, Avago, Avaya, Nortel, Alcatel-lucent, Dahua, Hikvision, Ericsson, MikroTik, Fortinet, Nokia, Nvidia, etc. |
Product Features
- Compliant with SFF-8431 and SFF-8472; Compliant with SFP28 MSA Specification
- Digital Diagnostic Monitoring available via 2-wire serial interface
- Up to 25.78Gb/s bi-directional data links, up to 10km on 9/125um SMF
- Hot-pluggable SFP footprint, Class 1 laser safety certified
- Low power dissipation, RoHS compliance
