4GE+2POTS+1USB+2.4G+5.8G(1200M)wifi XPON ONU
4GE+2POTS+1USB+2.4G+5.8G(1200M)wifi XPON ONU
EW-F6032P: 4*10/100/1000M Ethernet interface (RJ45), 1 EPON & GPON adaptive interface, 2*POTS, 1*USB interface, 2.4G WIFI & 5G WIFI.
Product Overview
EW-F6032P provides 4*10/100/1000M Ethernet interfaces, an EPON & GPON adaptive PON interface, 2*POTS voice ports, 1*USB and 2.4G/5G dual-band WiFi, making it well-suited for home or small-office deployments requiring two independent voice lines.
Technical Parameter
| Item | EW-F6032P |
|---|---|
| User Interface | 4*10/100/1000M RJ45, 2*POTS, 1*USB, 2.4G/5G WiFi |
| PON | EPON&GPON mode adaptive, SC-UPC/SC-APC; GPON: upstream 1.25Gbps/downstream 2.5Gbps |
| Size | 160mm(L)x112mm(W)x32mm(H) |
| Power supply | 12V 1.5A DC |
| Power consumption | <12W |
| POTS Port | 2*RJ11, Max 1km distance, Balanced Ring 55V RMS |
| Management | WEB/TELNET/TR069/OMCI/OAM |
Product Features
Voice Service Functions
- Heartbeat function supporting main producing soft exchange platform
- Supports SIP (IMS-compatible), H.248, MGCP VoIP protocols
- Supports 2 POTS interfaces with three-party call and local mixing
- Supports ITU-T G.711, G.723.1, G.729 compression algorithms
- 7×24 hour call loss ≤0.01%
General
- Support device-based rate limitation and bandwidth control
- Compliant with IEEE802.3ah & ITU-T G.984.x standard
- Up to 20KM transmission distance
- Support Dynamic Bandwidth Allocation (DBA)
- Support ONU auto-discovery / Link detection / remote upgrade of software
- Support multi-SSID (Maximum 4 SSID), automatic channel selection, hide SSID
- Support wireless security: 64/128 bit WEP, 802.1x, WPA and WPA2
| User Interface | 4*10/100/1000M RJ45, 2*POTS, 1*USB, 2.4G/5G WiFi |
| Size | 160mm(L)x112mm(W)x32mm(H) |
| Power supply | 12V 1.5A DC |
| Power consumption | <12W |
- Support device-based rate limitation and bandwidth control
- Compliant with IEEE802.3ah & ITU-T G.984.x standard
- Up to 20KM transmission distance
- Support Dynamic Bandwidth Allocation (DBA)
- Support ONU auto-discovery / Link detection / remote upgrade of software
- Support multi-SSID (Maximum 4 SSID), automatic channel selection, hide SSID
- Support wireless security: 64/128 bit WEP, 802.1x, WPA and WPA2
- Supports two-line VoIP (SIP/H.248/MGCP) with 7×24 call loss ≤0.01%
Product Overview
EW-F6032P provides 4*10/100/1000M Ethernet interfaces, an EPON & GPON adaptive PON interface, 2*POTS voice ports, 1*USB and 2.4G/5G dual-band WiFi, making it well-suited for home or small-office deployments requiring two independent voice lines.Technical Parameter
| Item | EW-F6032P |
|---|---|
| User Interface | 4*10/100/1000M RJ45, 2*POTS, 1*USB, 2.4G/5G WiFi |
| PON | EPON&GPON mode adaptive, SC-UPC/SC-APC; GPON: upstream 1.25Gbps/downstream 2.5Gbps |
| Size | 160mm(L)x112mm(W)x32mm(H) |
| Power supply | 12V 1.5A DC |
| Power consumption | <12W |
| POTS Port | 2*RJ11, Max 1km distance, Balanced Ring 55V RMS |
| Management | WEB/TELNET/TR069/OMCI/OAM |
Product Features
Voice Service Functions
- Heartbeat function supporting main producing soft exchange platform
- Supports SIP (IMS-compatible), H.248, MGCP VoIP protocols
- Supports 2 POTS interfaces with three-party call and local mixing
- Supports ITU-T G.711, G.723.1, G.729 compression algorithms
- 7×24 hour call loss ≤0.01%
General
- Support device-based rate limitation and bandwidth control
- Compliant with IEEE802.3ah & ITU-T G.984.x standard
- Up to 20KM transmission distance
- Support Dynamic Bandwidth Allocation (DBA)
- Support ONU auto-discovery / Link detection / remote upgrade of software
- Support multi-SSID (Maximum 4 SSID), automatic channel selection, hide SSID
- Support wireless security: 64/128 bit WEP, 802.1x, WPA and WPA2
